BALLUFF CAPACITIVE PROXIMITY SENSOR, TUBULAR, 12MM DIAMETER X 75MM BODY, POLYBUTYLENE TEREPHTHALATE HOUSING, PNP, N.O., 4MM SENSING DISTANCE, FLUSH, 100 HZ SWITCHING FREQUENCY, IP67, 4-PIN M12 QUICK-DISCONNECT.
| Brand | Balluff |
| Item | Proximity sensor |
| Additional Information | Purchase cable separately |
| IP Rating | IP67 |
| Operating Temperature | -25 to 85 deg C |
| Connection | 4-pin M12 quick-disconnect |
| Sensor Type | Capacitive |
| Operating Voltage | 10-30 VDC |
| Housing Size | 12mm diameter x 75mm body |
| Housing Material | Polybutylene terephthalate |
| Application | Standard duty |
| Shape | Tubular |
| Barrel Type | Threaded |
| Adjustable | Yes |
| Number of Wires | 3 |
| Switching Output | PNP |
| Operation Mode | N.O. |
| Sensing Distance | 4mm |
| Mounting Type | Flush |
| IO-Link Compatible | No |
| Switching Frequency | 100 Hz |
| Weld Field Immune | No |
| Chip Immune | No |
| Includes | Mounting hardware and adjustment tool |
