FUJI ELECTRIC BM3R SERIES MANUAL MOTOR PROTECTOR, ROTARY, 32A, THERMAL OVERLOAD, 24.0-32.0A ADJUSTABLE, 416A INSTANTANEOUS TRIP RATING, OPEN, 45MM FRAME.
| Brand | Fuji Electric |
| Item | Motor protector |
| Additional Information | For UL Type E listing, terminal cover BZ0TCRE and Short Circuit Alarm contact block BZ0TKUAB must be added to the MMS. Suitable as a motor disconnect |
| Actuator Type | Rotary |
| Connection | Screw terminal |
| Mounting | 35mm DIN rail |
| Series | BM3R |
| UL Rating | UL 508 rated |
| Relay Type | Thermal overload |
| Voltage Rating | 600 VAC |
| Amperage Rating | 32A |
| Number of Poles | 3 |
| Enclosure Type | Open |
| Power Poles | (3) N.O. |
| Horsepower Rating | 20hp |
| Full Load Amperage Range | 24.0-32.0A adjustable |
| Operation Type | Bi-metallic |
| Trip Class | Trip Class 10 |
| Phase Loss Sensitive | Yes |
| SCCR Rating | 50kA SCCR |
| Starter Type | Manual |
| Ground Fault Protection | No |
| Frame | 45mm |
| Instantaneous Trip Rating | 416A |
