METROL LIMIT SWITCH, SLIDING/ANGLED, PRECISION TOUCH, 12MM DIAMETER, THREADED, 1MM PITCH, 59.5MM LENGTH, 5MM RADIUS HEAD, STAINLESS STEEL, 10MM PLUNGER, 1.5N CONTACT FORCE, (1) N.C. CONTACT(S), 6.5FT/2M CABLE LENGTH, PIGTAIL.
| Brand | Metrol |
| Item | Limit switch |
| Switch Type | Precision touch |
| Actuator Type | 10mm plunger |
| Contact Type | (1) N.C. |
| Material | Stainless steel |
| IP Rating | IP65 |
| Operating Temperature | 0 to 80 deg C |
| Connection | Pigtail |
| Conductor Size | 30 AWG |
| Cable Length | 6.5ft/2m |
| Head Type | 5mm radius |
| Application | Sliding/angled |
| Barrel Type | Threaded |
| Includes | Mounting hardware |
| Length | 59.5mm |
| Stroke | 2.8mm |
| Head Material | Stainless steel |
| Diameter | 12mm |
| Indicating Type | LED indication |
| Contact Force | 1.5N |
| Repeatability | 0.005mm |
| Thread Pitch | 1mm |
