METROL LIMIT SWITCH, PRECISION TOUCH, 5MM DIAMETER, SMOOTH, 40MM LENGTH, 1.5MM RADIUS HEAD, STAINLESS STEEL, 2MM PLUNGER, 1N CONTACT FORCE, (1) N.O. CONTACT(S), 9.8FT/3M CABLE LENGTH, 90 DEGREE EXIT, PIGTAIL.
| Brand | Metrol |
| Item | Limit switch |
| Switch Type | Precision touch |
| Actuator Type | 2mm plunger |
| Contact Type | (1) N.O. |
| Material | Stainless steel |
| IP Rating | IP65 |
| Operating Temperature | 0 to 80 deg C |
| Connection | Pigtail |
| Conductor Size | 26 AWG |
| Cable Length | 9.8ft/3m |
| Cable Exit | 90 degree |
| Head Type | 1.5mm radius |
| Barrel Type | Smooth |
| Length | 40mm |
| Stroke | 2mm |
| Head Material | Stainless steel |
| Diameter | 5mm |
| Indicating Type | LED indication |
| Contact Force | 1N |
| Repeatability | 0.005mm |
