DURAPULSE GS10 SERIES AC MICRO DRIVE, ENCLOSED, 120 VAC, 1/4HP WITH 1-PHASE INPUT, SVC OR V/HZ MODE, A1 FRAME, RS-485, INTEGRATED DYNAMIC BRAKING.
| Brand | DURApulse |
| Item | Drive |
| For Use With | 3-phase induction and permanent magnet AC motors |
| IP Rating | IP20 |
| Mounting | Panel or wall |
| Series | GS10 |
| Voltage Type | AC |
| Frame Size | A1 |
| Amperage Rating | 1.6A |
| Enclosure Type | Enclosed |
| Load Current | 3A/point relay, 50 mA/point discrete |
| Communication Port and Connection Type(s) | (1) RS-485 (RJ45) |
| Port Protocol(s) | Modbus RTU Slave + Modbus ASCII Slave |
| Port Speed(s) | up to 38.4k baud |
| Relay Configuration | (1) Form C (SPDT) relay |
| Output Type | PWM output |
| Connector Type | Spring clamp terminals |
| Number of Input Phases | 1 |
| Number Of Input Channels | 1 |
| Number Of Output Channels | 1 |
| Input Current Signal Range | 0-20 mA and 4-20 mA |
| Input Voltage Signal Range | 0-10 VDC |
| Output Voltage Signal Range | 0-10 VDC |
| Number of Analog Input Channels | 1 |
| Analog Input Signal Type | Current/voltage |
| Number of Points per Analog Input Common | 1 |
| Input Resolution | 12-bit |
| Temperature Rating | -20 to 50 deg C |
| Output Resolution | 12-bit |
| Discrete Input Type | Sinking/sourcing |
| Number of Non-Isolated Discrete Input Commons | 2 |
| Discrete Output Type | Relay/sinking/sourcing |
| Number of Non-Isolated Discrete Output Commons | 1 |
| Fuse Type | User-supplied external fuse |
| Number of Points per Discrete Input Common | 3 |
| Number of Points per Discrete Output Common | 1 |
| Number of Discrete Input Points | 5 |
| Number of Discrete Output Points | 2 |
| Number of Isolated Discrete Output Commons | 1 |
| Number of Non-Isolated Analog Input Commons | 1 |
| Number of Analog Output Channels | 1 |
| Analog Output Signal Type | Voltage |
| Number of Non-Isolated Analog Output Commons | 1 |
| Number of Points per Analog Output Common | 1 |
| Controller Type | Micro |
| Nominal Drive Input Voltage | 120 VAC |
| Nominal Drive Output Voltage | 230 VAC |
| Number of Output Phases | 3 |
| Horsepower By Input Phase | 1/4hp with 1-phase input |
| Variable Torque Amperage Rating | 1.8A |
| Control Mode | SVC or V/Hz |
| Safe Torque Off (STO) | No |
| Dynamic Braking | Integrated dynamic braking |
| Input Signal | 4-20 mA, voltage or potentiometer input |
| Reverse Capability | Built-in |
| Internally Bypassed | No |
| Carrier Frequency Range | 2-15 kHz |
| Output Frequency Range | 0.1-599 Hz |
| Nominal Discrete Input Voltage | 24 VDC |
| Nominal Discrete Output Voltage | 240 VAC and 48 VDC |
