SAGINAW ENCLOSURE, NEMA 1, 16 X 16 X 6IN (HXWXD), WALL MOUNT, CARBON STEEL, ANSI 61 GRAY, POWDER COAT FINISH, SINGLE-DOOR, 1/4-TURN SEMI-FLUSH LATCH.
| Brand | Saginaw |
| Item | Enclosure |
| Color | ANSI 61 gray |
| Material | Carbon steel |
| IP Rating | IP30 |
| Mounting | Wall |
| NEMA Rating | 1 |
| Slope Top | No |
| Nominal Enclosure Dimensions | 16 x 16 x 6in (HxWxD) |
| Enclosure Height | 16.38in |
| Enclosure Width | 16.38in |
| Enclosure Depth | 6.12in |
| Integral Mounting Feet | No |
| Integral Mounting Flange | No |
| Dual Access | No |
| Knockouts | No |
| Finish | Powder coat |
| Cover Type | Single-door |
| Padlockable | No |
| Keylocking | No |
| Latch Type | 1/4-turn semi-flush latch |
| Subpanel | Purchase subpanel separately |
| 3-Piece Assembly | No |
| Vented | No |
| Bottom Gland Plate | No |
| Number Of Latches | 1 |
| Shelf | No |
| Hinge Type | Butt hinges |
| Number of Hinges Per Door | 2 |
