SOLO MODULAR TEMPERATURE CONTROLLER, MAIN MODULE, CURRENT, VOLTAGE, THERMOCOUPLE OR RTD INPUT, PULSE AND RELAY OUTPUT, (1) 3A FORM A (SPST) RELAY, 24 VDC, RS-485.
| Brand | SOLO |
| Item | Modular temperature controller |
| Mounting | 35mm DIN rail |
| Output | 12 VDC pulse, 3A SPST relay |
| Operating Voltage | 24 VDC |
| Input Current Signal Range | 0-20 mA, 4-20 mA |
| Input Voltage Signal Range | 0-5 VDC, 0-10 VDC, 0-50 mVDC |
| Input Thermocouple Signal Type | J, K, T, N, E, R, S, B, L, U, TXK |
| Input RTD Signal Types | Pt100 and JPt100 |
| Communication | RS-485 |
| Control Mode | PID, ON/OFF, ramp/soak or manual |
| Control Function | Single loop, heat only, cool only or heat/cool |
| Module Type | Main module |
